Hot Water Tank Fuel Less Generator





























Parts List


1. silicone oil ( non flammable non electrically conductive oil )


2. vacuum tank


3. intake air filter


4. intake dampener valve ( prevents vacuum tank implosion allowing air in at adjustable level)


5. high vacuum tank


6. air pressure tank


7. system run cycle air pressure, air pressure replacement for subsequent system "re start" control valve


8. high vacuum flow pipe control valve / solenoid actuation - electric


9. hydraulic oil pressure control valve / solenoid actuation - electric


10. vacuum draft impeller


11. hydraulic impeller


12. electric drive motor, sealed gas type - explosion proof


13. 1:50 ratio gear set high side tandem rotation with rotation of number 14, vacuum pump


14. vacuum pump


15. high voltage generator with permanent magnet magneto ( magneto feeds the field

      coil / stator of the generator ) sealed type ( inert Nobel gas),  - explosion proof


16. magneto voltage regulator


17. permanent magnet magneto - generator


18. oil pump


19. circuit breaker box / fuse block - connects it's out put to the house wiring


20. control board - system mapping - control electronic circuit board - governs the total system

      for safe operation


21. air compressor  - "piston type" contains electric drive motor 90 degree differential / planetary

      gear and electric clutch- also acts as a vacuum pump to then lower the pressure in the

      vacuum tank , number 5 when the flow selection valve , number 29 is in the specified position.


22. air pressure selection valve - directs the flow of air pressure


23. air compressor intake air filter


24. high voltage generator "voltage regulator" - out put electricity voltage regulator


25. valve / flow pipe coupling - compression fitting


26. valve / flow pipe coupling - compression fitting


27. max pressure - over pressure safety valve vents over pressure


28. max vacuum inlet dampener allow the vacuum to then be reduced by air inlet electric

      vacuum sensor - reports to the system logic mapping control electronic circuit board


29.  flow control valve - solenoid actuation multi port selection valve


30. oil fill tube  and pressure safety compression cap acts as redundant safety valve to then release

      pneumatic over pressure


31. R.P.M.( revolutions per minute) sensor - "hall effect" sensor measures rotation rate.

      The sensor assist to govern total speed of the system causes the mapping control electronics

      to then reduce or increase the flow rate by then causing the valve

      position solenoid's to adjust their position, also effects the electricity reintroduction

      rate ie.... electricity level to the system's electric motors' both within the air compressor housing

      and the drive line electric motor.


* Note - a percentile of the generated electricity is redirected from the main high voltage

             generator, number 15 - voltage regulated and controlled for level - via potentiometer, then

             directed, via wire, back to the electric drive motor, number 12 to then make the total

             system "baug resistant",   ie... the generator then will not slow down due to loading / loading

             is electrical demand then places upon the generator.


             The air compressor / vacuum pumps systems are then in the same fashion

             obtaining it's components electric current requirements ( ie... the internal electric motor and

             the mechanical electrically actuated electric clutch) from the high voltage

             generator, number 15. The system will not require the air compressor

             vacuum pump to then  "operate" all the time - this reduces fatigue upon the design system

             and adds to the longevity of the mechanism. When the internal electric clutch are "disengaged"

             the air compressor and piston and piston crank system then are not moving.


The "Start" sequence then requires the valves, number 29 and number 9, in the correct position so that the vacuum cycle is opened causing incline rotation by stored vacuum within the system. This allows the pneumatically pressurized oil to then begin its "draft cycle".  The draft cycle is then defined - by pump pulling hydraulic oil across a hydraulic impeller in the flow system before the pump, to then, with a ratio gear set, cause incline rates of rotation in the total system.
